XTM 20A MPPT Solar Controller
Details
https://www.bcf.com.au/p/xtm-20a-mppt-solar-controller/613766.htmlPromotions
Special Offer
Additional Information
Product Info
Product Info
Boost your solar panel system's performance with the XTM 20A MPPT Solar Controller. Thanks to cutting-edge MPPT technology, you'll harness up to 99% of your solar panel's potential, making every ray of sunshine count.
Safety is paramount, and this XTM solar controller delivers. It's armed with overload and short-circuit protection, so you can rest easy knowing your system is secure. Plus, the aluminium housing keeps things cool, reducing wear and tear.
Whether you're setting up a 12V or 24V solar panel system off the grid, this controller is your trusted companion. It's compatible with various battery types, including sealed, gel, flooded, LiFePO4, and Li(niCoMn)02 batteries.
Don't let a single sunbeam go to waste – the XTM 20A MPPT Solar Controller is here to maximise your solar power system's potential.
Safety is paramount, and this XTM solar controller delivers. It's armed with overload and short-circuit protection, so you can rest easy knowing your system is secure. Plus, the aluminium housing keeps things cool, reducing wear and tear.
Whether you're setting up a 12V or 24V solar panel system off the grid, this controller is your trusted companion. It's compatible with various battery types, including sealed, gel, flooded, LiFePO4, and Li(niCoMn)02 batteries.
Don't let a single sunbeam go to waste – the XTM 20A MPPT Solar Controller is here to maximise your solar power system's potential.
Features
- Maximise the power from the solar panels with up to 99% MPPT efficiency
- Suitable for 12V or 24V systems for different off-grid setupsÂ
- Overload & short circuit protection for safety
- Maintains optimal operating temperature extending the life of your solar controller and panels
- Ample capacity for charging / discharging with 20A
- Max panel power: 260W(12V), 520W(24V)Â
- Aluminium housing for better cooling
- Works with a wide range of batteries: sealed, gel, flooded, LiFePO4, and Li(niCoMn)02Â
- Optimise the energy harvesting process increasing overall solar panel performance
- Provides stable power to your devices while preventing overcharging or discharging to extend battery’s lifeÂ
Tech Spec
XTM 20A MPPT SOLAR CONTROLLER
MODEL | Tracer 2206AN |
---|---|
SYSTEM RATED VOLTAGE | 12/24V DC Auto-recognition |
RATED CHARGING CURRENT | 20A |
RATED DISCHARGE CURRENT | 20A |
CONTROLLER VOLTAGE RANGE | 60V - 46V |
MPPT VOLTAGE RANGE | (Battery voltage +2V) 36V |
PV RATED CHARGE POWER | 260W at 12V | 520W at 24V |
SELF-CONSUMPTION | < 12mA |
DISCHARGE CIRCUIT VOLTAGE DROP | < 0.23V |
DIMENSIONS | 220 x 154 x 52mm |
MOUNTING DIMENSIONS | 170 x 145mm |
WIRE SIZE | 6AWG (16mm²) |
RECOMMENDED CABLE | 10AWG (6mm²) |
WEIGHT | 0.94kg |
